Model NO.
SPL101
Panel Light, Low Glare, High Lumen Efficacy
Quantity:

When you intend to wholesale bulk High-quality Suspended Led Panel Lights, you will do some search to study which one is better and whether it fits your customers' needs. Come to Senselight, we as the reliable manufacturers in China can help you settle your problems.
First comes the features of our Suspended Led Panel Lights of Class I Lighting. The Suspended Led Panel Light is specially designed. The light forms a uniform plane and luminous effect after passing through the light guide plate with high transmittance. It has favorable illumination uniformity, soft light and making people feel comfortable and bright. Moreover, it can effectively alleviate eye fatigue. In terms of green lighting design, environmental protection materials, low power consumption, luminous efficiency and lighting brightness should be better than grid lamps, so as to truly enjoy lamps during the day and lighting at night.

Then comes the advantages of suspended led panel lights of Class I Lighting.
Environmentally friendly and pollution-free fuel and gas, recyclable.
Healthy light is soft and not dazzling.
Energy saving replaces traditional energy-saving lamps and saves more power.
The panel lamp adopts LED as the light source and the side light-emitting light guiding principle. The light source is reflected into an area light source on the surface of the lamp board through the light guiding of internal polymer materials, so as to meet the requirements of uniform and soft lighting.

Finally comes the installation of suspended led panel lights.
Fix the hanging wire installation part on the congenital flower board, and lock the screw. The hanging wire is vertical, and hang the component on the back of the LED panel lamp. Welcome to send us an inquiry for more details about our products.

Product Features

  • White finish aluminium frame and opal diffuser

  • Available in 3 sizes: 595x595, 295x1195 and 595x1195mm

Overview

Product Range: LED panel light

Application: Offices, industrial, commercial, residential

Housing: Extruded aluminium profile with white powder coated finish

Diffuser: High efficiency low glare opal diffuser

Light Source: LED SMD

Driver: Remoted driver with flex and plug option

Electrical Class: Class I, requires earth

Mounting: Recessed/Ceiling grids/Surface Mounted/Suspending

Optional Function: Dimmable, CCT changeable, Emergency

Warranty: 3 Years

Certificates: CE/EMC/SAA/ROHS

Performance

Voltage Rating(V): 220-240V

Operating Frequency (Hz): 50/60Hz

Wattage Rating: 30W/32W/36W/40W

Dimension(L*W*H): 595*595*9MM;1195*295*9MM;620*620*9MM;1220*320*9MM

Lumen Output: 3200LM/5200LM

Lumens Per Circuit Watt: 80-140lm/W

Correlated Color Temperature: 3000K/4000K/6500K

Color Rendering Index: >80

Power Factor: >0.9

SDCM:<6

Beam Angle: 120°

IP Rating: IP20

Energy Rating: A++

LED Life (Hours): 30,000
