Model NO.
SOF147
Delivery:
FOB
Linkable Led Linear Light, Surface Mounted & Suspending
Quantity:

Are you looking for led batten? Sense will meet your needs. As a professional led batten supplier in China, we have a wide variety of led battens for you to choose from, which have passed the strict safety and quality certification to ensure that you are using high quality and high performance assured products. Welcome to contact us for wholesale purchase at any time.

Product Features

Slim appearance, no visible screws

Infinite linkable

Pendant light with stainless steel cable

Stand 100LM/W, up to 120LM/W

Overview
Product Range: IP20,Linear lighting
Application: Retail, offices, schools, corridors, workshops
Housing:High quality Aluminium with white/black coated
Diffuser:Milky prism diffuser
Light Source: LED SMD
Electrical Class: Class I
Mounting: Surface Mounted/Suspending
Optional Function:  Emergency,DALI dimmable
Warranty: 5 Years
Certificates: CE/EMC/SAA/ROHS
Performance
Voltage Rating(V): 220-240V
Operating Frequency (Hz): 50/60Hz
Wattage Rating: 24W/40W/50W/80W
Dimension(L*W*H): 600/1200/1500/3000*64*78.4MM
Lumen Output: 2400LM/4000LM/5000LM/8000LM/
Lumens Per Circuit Watt: 100~120lm/W
Correlated Color Temperature: 3000K/4000K/6500K
Color Rendering Index: >80
Power Factor: >0.9
SDCM:<6
Beam Angle:75°
IP Rating: IP20
Energy Rating: A++
LED Life (Hours): 50,000



The led linear batten adopts a durable aluminum structure to ensure stability and corrosion resistance. And it can provide enough heat dissipation, effectively absorb the heat, prevent the heat concentration is too high to lead to the performance of this led linear batten decline. When the beam Angle is 75°, the optical emission produced by the opalescent prism diffuser is very uniform and there is no multiple shadow effect. The linkable led batten has a wide range of lumens, ranging from 2400LM to 8000LM. The smd chip used in it provides excellent lumen maintenance and excellent stability for the strip. Compared to traditional fluorescent lighting fixtures, led batten provides greater energy savings and lower maintenance costs.
Slim appearance, no visible screws
Infinite linkable
Pendant light with stainless steel cable
Stand 100LM/W, up to 120LM/W
